 Post subject: Son of The Grenade
PostPosted: Mon Jun 27, 2011 10:23 pm
Offline
proff. patpending
User avatar

Joined: Wed May 06, 2009 8:20 pm
Posts: 14716
Current ride: Victoria Sponge
Location: Bristol - Gateway to all things good
The Grenade got married to a beautiful S1W called Snowflake and they were blessed with a son...

Engine is coming together nicely, cam cover cut down, bronze oil pump gear fitted, top end swapped over to something more modern and squish set nicely...
Attachment:
sotg squish.jpg


Target was 0.75mm, so quite pleased with the result with a 0.25mm base gasket and 0.75mm head gasket...

Parents very proud...


You do not have the required permissions to view the files attached to this post.

_________________
08 Specialized Langster


Top


 Post subject: Re: Son of The Grenade
PostPosted: Mon Jun 27, 2011 10:54 pm
Offline
User avatar

Joined: Wed May 06, 2009 4:03 pm
Posts: 4633
Current ride: S1w X1 1125CR
Location: NNW of Sarfampton
Frankenstein??

_________________
I'm a Hornithologist, I get excited by exotic birds.........


Top


 Post subject: Re: Son of The Grenade
PostPosted: Mon Jun 27, 2011 10:58 pm
Offline
proff. patpending
User avatar

Joined: Wed May 06, 2009 8:20 pm
Posts: 14716
Current ride: Victoria Sponge
Location: Bristol - Gateway to all things good
They haven't named him yet...

_________________
08 Specialized Langster


Top


 Post subject: Re: Son of The Grenade
PostPosted: Sat Jul 16, 2011 5:38 pm
Offline
proff. patpending
User avatar

Joined: Wed May 06, 2009 8:20 pm
Posts: 14716
Current ride: Victoria Sponge
Location: Bristol - Gateway to all things good
pash wrote:
Parents very proud...



_________________
08 Specialized Langster


Top


 Post subject: Re: Son of The Grenade
PostPosted: Sat Jul 16, 2011 7:14 pm
Offline

Joined: Wed Feb 23, 2011 11:01 pm
Posts: 511
Current ride: K1300
Grewflake :?:

Nice engineering :yup: Jealous of your engine lift/frame


Top


 Post subject: Re: Son of The Grenade
PostPosted: Sat Jul 16, 2011 9:00 pm
Offline
User avatar

Joined: Tue May 05, 2009 8:00 pm
Posts: 10234
Current ride: X1 2001 White Riot
Location: southampton
pash wrote:
pash wrote:
Parents very proud...




:mrgreen: :yup:

_________________
Obey the principles without being bound by them.
Bruce Lee


Top


 Post subject: Re: Son of The Grenade
PostPosted: Sun Jul 17, 2011 9:21 am
Offline
User avatar

Joined: Fri May 15, 2009 5:34 pm
Posts: 3581
Location: The borders of insanity
Bikerhoss wrote:
Grewflake :?:
Snownade :?:

_________________
Sept 2017. Email will find me.


Top


 Post subject: Re: Son of The Grenade
PostPosted: Fri Aug 05, 2011 10:37 pm
Offline
proff. patpending
User avatar

Joined: Wed May 06, 2009 8:20 pm
Posts: 14716
Current ride: Victoria Sponge
Location: Bristol - Gateway to all things good
Son of Grenade's engine is still waiting to be bolted together, purely through not having time on my side (and a lawnmower on the bike lift), however interesting snippet here regarding reuse of Buell parts. Nothing new here, but have never seen a photo of these bits together:
Attachment:
S1 Silver 034.jpg


So from left to right, we have:
32402-83 - Trigger rotor for S2, S1, M2 and early S3s
32422-98 - Trigger rotor for X1 and late S3s
32473-02 - Trigger rotor for 03 to 07 XBs

Something to note is the difference in keyway position between the 32422-98 and 32473-02. I always believed this to be 90 degrees but in actual fact it is more... This is due to the position of the keyway on the crank driven cam, which changed on the XB and is the reason why you can't just bolt an early trigger rotor on an XB to run with a carb, see this post... And before you ask, the Cam Position Sensor does not have enough movement...

But, if you wanted to run with XB cams in an X1 (same as Screaming Eagle "E" grind with a whopping 0.551" of lift - but reading herethey don't perform as well as the 0.536"s which have a longer duration - also the timing marks are in the wrong place cos the front and rear inlet cams are swapped), you would need to use an XB trigger rotor.

If you wanted to run the sweet performing SE 0.497 (standard in S1, S3, M2, X1) on an XB, you would need the X1/S3 timing rotor (which is no longer available, although the big blue bird that lives on the shore of the Tame carries stock) and also work out the timing - although word has it that cam sets bought now have Vs for XB timing and Os for tuber timing.


You do not have the required permissions to view the files attached to this post.

_________________
08 Specialized Langster


Top


 Post subject: Re: Son of The Grenade
PostPosted: Fri Aug 05, 2011 10:58 pm
Offline

Joined: Wed Feb 23, 2011 11:01 pm
Posts: 511
Current ride: K1300
:?: Didn't understand most of that, but I read it over at least twice cause I love the engineering :D
Must get my lazy ass on a mechanics course :oooops:


Top


 Post subject: Re: Son of The Grenade
PostPosted: Fri Aug 05, 2011 11:03 pm
Offline
User avatar

Joined: Tue May 05, 2009 8:00 pm
Posts: 10234
Current ride: X1 2001 White Riot
Location: southampton
:yup: the final plan being "as cunning as a fox who's just been appointed Professor of Cunning at Oxford University"

_________________
Obey the principles without being bound by them.
Bruce Lee


Top


 Post subject: Re: Son of The Grenade
PostPosted: Fri Aug 05, 2011 11:07 pm
Offline
Nanny Brown
User avatar

Joined: Sat May 23, 2009 10:22 pm
Posts: 6453
Location: Portsmouth, UK
Nice one! lOl I always enjoyed Blackadders' comments to Baldrick.... lol

_________________
Valencia Orange XB12Scg - serviced by Maz 2018
Black P3 Blast - serviced by Maz and fixed by Maz in 2019


Top


 Post subject: Re: Son of The Grenade
PostPosted: Fri Aug 05, 2011 11:07 pm
Offline
proff. patpending
User avatar

Joined: Wed May 06, 2009 8:20 pm
Posts: 14716
Current ride: Victoria Sponge
Location: Bristol - Gateway to all things good
I was a bit bored... When the mower is off the bike lift, I'll take some pictures of the frame going on to the engine and point out some special bits...

_________________
08 Specialized Langster


Top


 Post subject: Re: Son of The Grenade
PostPosted: Fri Aug 05, 2011 11:09 pm
Offline
User avatar

Joined: Tue May 05, 2009 8:00 pm
Posts: 10234
Current ride: X1 2001 White Riot
Location: southampton
hurry up then enquiring minds need pictures :mrgreen:

_________________
Obey the principles without being bound by them.
Bruce Lee


Top


 Post subject: Re: Son of The Grenade
PostPosted: Tue Aug 09, 2011 6:17 pm
Offline
User avatar

Joined: Tue May 19, 2009 8:42 pm
Posts: 467
Location: my shed, Hampshire
can you build me an engine one day! sounds like you have to much time on your hands pash!!

_________________
BUELL-Turning riders into mechanics since 1983!!!


Top


 Post subject: Re: Son of The Grenade
PostPosted: Tue Aug 09, 2011 6:55 pm
Offline
proff. patpending
User avatar

Joined: Wed May 06, 2009 8:20 pm
Posts: 14716
Current ride: Victoria Sponge
Location: Bristol - Gateway to all things good
I don't have enough time to do my own stuff, besides you would be better of getting someone to build your engine who knows what they are doing, like Maz or Tubbs...
